Alstom Over current & Earth fault Protection relay CDG31EG004SBCH
Product Details:
X
Product Description
Technical Specification
- Type Electro Mechanical Relay
- Protection Type Over current & Earth fault Protection(IDMT Relay)
·
NON DIRECTIONAL INV TIME 3O/C OR 2O/C&1E
·
|
Technical Specifications |
|
|
Model No : |
CDG31EG004SB(M) |
|
Relay type |
CDG 31 |
|
APPLICATION |
2 O/C + 1 E/F |
|
BURDEN / D.M.T |
3 VA /3 SEC. |
|
C.T. SECONDARY |
1 AMP CT. |
|
CASE SIZE |
3D HORZ. |
|
CONTACTS (S/R OR H/R) |
2 N/O S/R |
|
E/F SETTING |
0.1 - 0.4 Amps. |
|
FLAG |
YES |
|
MOUNTING |
FLUSH |
|
O/C SETTING |
0.5 - 2 Amps. |
|
FREQUENCY |
50 HZ |
|
Name Plate |
RFG9126 901 |
|
Outline Diagram |
MFJ 014 |
|
Wiring Diagram |
MADZ802.63-1 |
