SIEMENS REYROLLE SOFTWARE DIGSI 5 ENGINEERING TOOLS

DIGSI 5 is the versatile engineering tool for parameterization, commissioning and operating all SIPROTEC 5 devices. Its innovative user interface includes context-sensitive user instructions. Simple connection to the device via USB enables you to work with a device easily and efficiently. The full capabilities of DIGSI 5 are revealed when you connect it to a network of protection devices: Then you can work with all of the devices in a substation in one project. DIGSI 5 offers superior usability and is optimized for your work processes. Only the information you actually need to carry out your tasks is shown. These can be reduced further using expanded filter mechanisms.

The consistent use of sophisticated, uniform mechanisms in the user interfaces requires less training.For the system engineering of DIGSI 5 parameterized devices, the IEC 61850 system configurator is used.The IEC 61850 system configurator is used for the system integration of DIGSI 4 devices. The IEC 61850 system configurator is the manufacturer-neutral solution for the interoperable engineering of IEC 61850 products and systems. The tool supports the SCL (Substation Configuration Description Language) configuration files from the IEC 61850-6 through import or export of all formats (ICD/IID/CID/SCD/SSD/SED). Thus, IEC 61850 devices can be added and a complete IEC 61850 station is available for the substation automation Technology.DIGSI 5 Premium Scientific(available for universities, colleges and research institutes).

With a PC or a notebook, you can parameterize the devices via the interfaces and export and visualize the fault data. DIGSI 5 comes in different variants (Compact, Standard, and Premium) that provide different functionalities:

• The Single-Line Editor allows you to define a substation and the primary equipment graphically. Connect those elements to the protection functions of your protection devices.
• The graphic display of the SIPROTEC devices can be designed and edited with the Display Editor as well as with a graphics program. Take your single-line diagram and convert it into a display picture. You can define your own symbols as well.
• You can configure additional functions like interlocking of the devices graphically with the CFC Editor.
• Graphic display with resolution of 1024768 (12801024 recommended)
