Alstom Motor Protection Relay Agile P253 (Numerical Relay)
Product Details:
X
Product Description
Technical Specification- Type: Numerical Relay
- Protection Type: Motor
- Voltage24V-240V
- AC\DC Operated Auxillary supply AC/DC
- Motor Protection Agile P253
The principal protection functions include thermal overload, negative sequence overcurrent, loss of load, prolonged start, locked rotor (starting / normal running), restricted earth fault, excessive number of starts and speed switch input. Additional versatility is provided through backup overcurrent and earth fault protection, with up to 3 independent stages, breaker fail and trip circuit supervision functions. The hardware capability is broadened by a sensitive earth fault CT option.
The user may assign any of the logical/physical statuses to binary inputs, outputs and programmable LEDs. All the output contacts are changeover type for ease of implementing the desired wiring schematic.
Key Features
- Optimized protection for motor applications
- Cost effective solution
- Measurement, protection and monitoring in one box
- Front USB port for local communication
- Flexible SCADA communication options
- Diagnostics/maintenance facilities Universal, wide-range auxiliary supply for procurement and inventory standardization
- Same form factor for feeder/motor relays
- Password protection for security
- Extensive self-supervision and internal diagnostics
