Siemens Ruggedcom Ethernet Switch RSG2300NC

Product Description

In sync with the market development and customer's desire, we are providing a wide range of Ethernet Switch. These are developed as per industry norms and parameters.

Features:

• Compact design
• Shock proof
• Rugged construction
• High strength
• Easy to use
• Rigid design

The Rugged Switch RSG2300NC is an industrially hardened, fully managed, modular, Ethernet switch specifically designed to operate reliably in electrically harsh and climatically demanding utility substation and industrial environments. The RSG2300NC's superior ruggedized hardware design coupled with the embedded Rugged Operating System (ROS)provides improved system reliability and advanced cyber security and networking features making it ideally suited for creating secure Ethernet networks for mission-critical, real-time, control applications.

The RSG2300NC's modular flexibility offers 10BaseFL /100BaseFX /1000BaseX fiber and 10/100/1000BaseTX copper port combinations. Optional front or rear mount connectors make the RSG2300NC highly versatile for any application and can support multiple fiber connectors (ST, MTRJ, LC, SC) without loss of port density. The RSG2300NC is packaged in a rugged galvanized steel enclosure with industrial grade DIN, panel, or 19 rack-mount mounting options.
Ethernet Ports:

• 24 10/100TX copper ports
• Optional: up to 4 1000LX Gigabit Ethernet ports (copper and/or fiber) and up to 8 100FX Fiber Fast Ethernet ports
• 2 port modules for tremendous flexibility
• Non-blocking, store and forward switching
• Supports many types of fiber (Multi mode, single mode, bi-directional single strand)
• Long haul optics allow distances up to 90 km
• Multiple connector types (ST, MTRJ, LC, SC)

Cyber Security Features:

• Multi-level user passwords
• SSL with 56-bit encryption
• Enable/disable ports, MAC based port security
• Port based net work access control (802.1x)
• VLAN (802.1Q) to segregate and secure net work traffic
• RADIUS centralized password management
• SNMPv3 authentication and 56-bit encryption

Management Tools:

• Web-based, Telnet, CLI management inter faces
• SNMP v1/v2/v3 (56-bit encryption)
• Remote Monitoring (RMON)
• Rich set of diagnostics with logging and alarms

Universal Power Supply Options:

• Fully integrated, dual-redundant (optional) power supplies
• Universal high voltage range: 88-300VDC or 85-264VAC
• Popular low voltage ranges: 24VDC(12-36VDC), 48VDC (36-59VDC)
• Screw or pluggable terminal blocks available
• Terminal blocks for reliable maintenance free connections
• CSA/UL 60950 safety approved to +85°C
