Product Description

Model : SOLID STATE FREQUENCY CONVERTER

Series : FRIVO

UDEY-FRIVO series AC POWER SOURCES are solid state frequency converters offering the most cost-effective and flexible way of providing dependable and accurate frequency and voltage conversion for low power single-phase applications.

Frequency converters are used to convert existing AC power supply into stable and pure sine wave power supply of required frequency. In UDEY-FRIVO series this is achieved through AC DC AC conversion. Microprocessor is used as its heart with SPWM circuits, IGBT module adopting technologies such as digital frequency division, D/A conversion, instantaneous feedback and Sinusoidal Pulse Width Modulation.

UDEY-FRIVO easily converts mains 220V AC 50 Hz supply to Variable Output Frequency and Variable Output frequency as under:

• 0 x 150 x 300V 50 Hz
• 0 x 150 x 300V 60 Hz
• 0 x 150 x 300V 45 - 70 Hz
• 0 x 150 x 300V 100 Hz (Not available in FRIVO 53 and 55)
• 0 x 150 x 300V 200 Hz (Not available in FRIVO 53 and 55)
• 0 x 150 x 300V 400 Hz

Control is via front panel knobs.

Machine Feature

• OUTPUT: Adjustable Frequency: 50Hz, 60HZ, 45–70Hz, 100Hz, 200Hz and 400Hz Adjustable Voltage in two ranges: 0x150x300V
• Pure Sine wave sinusoidal output
• Low harmonic distortion
• Digital display real time data: Frequency, Voltage, Current, Power and Power Factor
• Solid state with proven advanced IGBT and SPWM technology
• Protection for Short-circuit, Over-current, Over-load, Over-heat with audio alarm.

Simplicity in operation:

• Plug and socket connections with few knobs mean minimal operator training. LED digital displays for output Frequency, Voltage, Current, Power and Power Factor.
• Protection for Short-circuit, Over-current, Over-load and Over-heat is provided to ensure proper operation with audio alarm.
• UDEY-FRIVO is built in single unit sheet steel cabinets. Output is available on 3-pin sockets for connecting the load. The power supply is very compact and low in weight.

Applications:UDEY- FRIVO series are suitable for applications ranging from production-line testing through to research and development laboratories, workshops, shipyard, ship manufacturing and repair plants, etc.
